Upgrade your electrical connections with the 200A 250A Black Square Terminal from Renhotec. Made for durability and performance, these terminals are designed to handle heavy-duty applications efficiently. Trust Renhotec for reliable electrical components.
| Body Style | Square |
||
|---|---|---|---|
| Mounting Type | Panel Mount |
||
| Mounting Feature | Bulkhead |
||
| Insulation Material | Thermoplastic |
||
| Color | Red |
||
| Wire Gauge | 25m㎡, 70m㎡ |
||
| Body Style | Square |
Mounting Type | Panel Mount |
| Mounting Feature | Bulkhead |
Insulation Material | Thermoplastic |
| Color | Red |
Wire Gauge | 25m㎡, 70m㎡ |
| Rated Voltage | 1500V |
||
|---|---|---|---|
| Rated Current | |||
| Test Voltage | 4000V AC |
||
| Insulation Resistance | |||
| Rated Voltage | 1500V |
Rated Current | |
| Test Voltage | 4000V AC |
Insulation Resistance |
| Termination Thread | M8 |
||
|---|---|---|---|
| Mating Cycles | 100 |
||
| Termination Thread | M8 |
Mating Cycles | 100 |
| Contact Termination | Busbar, Screw |
||
|---|---|---|---|
| Contact Material | Stannum plating on copper alloy |
||
| Contact Finish | Tin Plating |
||
| Contact Termination | Busbar, Screw |
Contact Material | Stannum plating on copper alloy |
| Contact Finish | Tin Plating |
| Ingress Protection | IP55, IP68 |
||
|---|---|---|---|
| Operating Temperature | -40℃~125℃ |
||
| Flammability | UL94 V-0 |
||
| Salt Spray Resistance | 48H (Mating State) |
||
| Ingress Protection | IP55, IP68 |
Operating Temperature | -40℃~125℃ |
| Flammability | UL94 V-0 |
Salt Spray Resistance | 48H (Mating State) |
Breaking standard 600V/200A market limits, our Through-Wall Power Terminals deliver up to 600A/1000V capacity and +125°C automotive-grade thermal tolerance. With UL94 V-0 materials and IP67 sealing, they provide a future-proof, robust connection for modern ESS, EV batteries, and heavy-duty applications.
Engineered for seamless high-voltage integration, our Through-Wall Power Terminals are widely utilized in commercial Energy Storage Systems (ESS), Electric Vehicle (EV) battery enclosures, and heavy-duty Power Distribution Units (PDUs). By providing a secure, weather-resistant, and low-loss bulkhead connection, they are the ideal choice for engineers developing reliable power routing architectures in RVs, marine applications, and off-grid power stations.
As a group-level source manufacturer, Renhotec offers an extensive range of Through Wall Power Terminals. The chart below demonstrates our full manufacturing capabilities. You can find the corresponding meaning of each segment on your existing part numbers.
All certifications listed below are held by Renhotec or our verified manufacturing facilities, ensuring full compliance with international automotive and safety standards.
Suitable for:
1. Lithium – ion battery packs (e – bikes, energy storage systems, etc.)
2. Lead – acid batteries (industrial starting, backup power supplies)
3. Special – purpose batteries (high – power batteries for forklifts, AGVs)
1000V DC & 1000V AC.
Standard current range: 60A – 500A; some models can reach up to 600A.
Panel – mounted, with mounting styles including Busbar, inner screw, outer screw, etc.
Available in brass or copper options. Generally, brass is used for currents below 300A, while copper is used for currents above 300A.
Housing: PA66 material; Flamability rating is UL94 -V0.
