IEC 62196-3 500A High-Efficiency CCS2 HPC Charging Connector for Electric Vehicles

Part NO.: RHTIEC3m-EV500LP-QFG Category:
  • 500A/500KW Ultra-Fast Charging
  • Integrated Liquid-Cooling Thermal System
  • Silver-Plated Low-Resistance Terminals
  • UL94 V-0 Flame-Retardant Safety
  • IEC 62196-3 Standard Compliance
Get A Quotation

Product Introduction

High-efficiency CCS2 HPC (High Power Charging) connector designed for the next generation of Electric Vehicles. Compliant with IEC 62196-3 standards, it supports a continuous 500A current and 500KW power output, integrating advanced liquid-cooling technology to ensure rapid, safe, and stable charging performance.

Key Benefits

  • • Ultra-High Current Capability: Supports up to 500A continuous charging for HPC stations.
  • • Advanced Thermal Management: Integrated liquid-cooling with 288W cooling device rated power.
  • • Superior Safety Compliance: UL94 V-0 flame-rated thermoplastic and IEC 62196-1 insulation standards.
  • • Low Insertion Force: Optimized mechanical design with ≤100N insertion/withdrawal force.
  • • High-Grade Connectivity: Silver-plated copper terminals for minimal contact resistance.
  • • Rugged IP55 Protection: Engineered for reliability in demanding outdoor charging environments.

Applications

HPC Fast Charging Station Application
  • Ultra-fast public charging stations (HPC)
  • Electric bus and heavy-duty vehicle fleet charging
  • Highway fast-charging corridor infrastructure
  • Liquid-cooled supercharging pile integration
  • EV testing and automotive R&D facilities

Product Type

CCS2 HPC charging connector
Voltage Current

500A Max.(continue)
Withstanding Voltage

3500V AC /1min
Protection(connector)

IP55
Insertion/withdrawal Force

≦100N
Conductor Size

35mm²(Cooled)
Plastic Part Material

Thermoplastic
Plug Terminal Type

Silver plated copper
Flame Class

UL94 V-0
Cooling Device Rated Current

12A
Cooling Device Rated Power

288W
Product Type

CCS2 HPC charging connector

 Voltage Current

500A Max.(continue)
Withstanding Voltage

3500V AC /1min

 Protection(connector)

IP55
Insertion/withdrawal Force

≦100N

 Conductor Size

35mm²(Cooled)
Plastic Part Material

Thermoplastic

 Plug Terminal Type

Silver plated copper
Flame Class

UL94 V-0

 Cooling Device Rated Current

12A
Cooling Device Rated Power

288W

Electrical Characteristics

Rated Voltage

1000V Ma
Power

500KW Max
Insulation Resistance

Rated Voltage

1000V Ma

 Power

500KW Max
Insulation Resistance

Environmental Characteristics

Operating Temperature

-30℃~50℃
Operating Temperature

-30℃~50℃

Contact Type

Contact Material

Copper Alloy
Contact Material

Copper Alloy
Product Type

CCS2 HPC charging connector
Rated Voltage

1000V Ma
Voltage Current

500A Max.(continue)
Power

500KW Max
Withstanding Voltage

3500V AC /1min
Insulation Resistance

Operating Temperature

-30℃~50℃
Protection(connector)

IP55
Insertion/withdrawal Force

≦100N
Conductor Size

35mm²(Cooled)
Contact Material

Copper Alloy
Plastic Part Material

Thermoplastic
Plug Terminal Type

Silver plated copper
Flame Class

UL94 V-0
Cooling Device Rated Current

12A
Cooling Device Rated Power

288W
