Engineered for high-current battery storage and power applications, our premium XT series connectors (including the popular XT30, XT60, and XT90 models) deliver reliable, low-loss power transmission ranging from 15A to 75A. Built with durable flame-retardant housings and anti-reverse, gold or nickel-plated contacts, they provide engineers and manufacturers with a secure, highly efficient wire-to-wire and board-to-board solution ideal for UAVs, e-mobility, and advanced battery management systems.
The XT series connectors are engineered for a comprehensive spectrum of high-current power and battery management applications. Delivering stable and low-loss power transmission, they are widely integrated into UAVs, RC models, and e-mobility solutions such as e-bikes and AGVs. Furthermore, their high reliability makes them an industry standard for residential energy storage systems, portable power stations, heavy-duty garden tools, and emerging smart commercial robots.
Industrial UAV & Flight Controllers
As a group-level source manufacturer, Renhotec offers an extensive range of XT Series connectors. The chart below demonstrates our full manufacturing capabilities. You can find the corresponding meaning of each segment on your existing part numbers.
All certifications listed below are held by Renhotec or our verified manufacturing facilities, ensuring full compliance with international automotive and safety standards.
The XT series supports a broad range of power requirements. The rated continuous/peak current spans from 15A (e.g., XT30 series) up to 75A (XT150 series). The rated voltage is typically between 500V DC and 600V DC, with specific low-voltage versions rated for 80V DC or 150V DC depending on the exact model.
To accommodate different equipment designs, the XT series offers multiple configurations. These include standard wire-to-wire connectors, vertical board-mounted (PB), horizontal board-mounted (PW), panel-mounted fixed plugs (E/EW), and center-split PCB embedded connectors (PM).
Yes. For applications requiring integrated battery management or communication, we offer power and signal hybrid configurations. Models such as the XT30(2+2), XT60(2+1), XT90(2+2), and XT120(2+4) combine high-current main contacts with additional 1A signal terminals within a single compact housing.
The housings are molded from highly durable PA66 engineering plastic. They can safely operate in extreme temperatures ranging from -20℃ to 120℃. The vast majority of the XT series features a UL94 V-0 flammability rating (the XT150 model is rated UL94 V-2), ensuring high safety standards for energy storage environments.
Yes. While the standard XT series provides a basic IP40 ingress protection rating, we manufacture specific sealed models (such as the XT60W and XT90HW) that achieve an IP65 waterproof rating, making them ideal for outdoor e-mobility or damp industrial environments.
Yes. For high-voltage and high-current applications where electrical arcing is a concern during plugging, we offer the XT90S female connector. It features a built-in anti-spark mechanism to protect sensitive components like flight controllers and BMS boards from surge damage.
For in-stock items, orders are typically processed and shipped within 1-2 business days. For standard configurations requiring new production, our agile manufacturing capabilities allow us to deliver in as fast as 7 to 14 days. We recommend contacting our sales team to verify real-time inventory for your specific Part Number.
You can easily request comprehensive product specifications and test samples by clicking the “Inquiry” or “Live Chat” button on our page. Our technical sales team will respond promptly to support your project design.
Renhotec provides a comprehensive One-Stop Solution from concept to mass production. Please note that project timelines scale with the complexity of your design - ranging from rapid modifications of standard connectors to fully bespoke mold developments.
A swift and successful product rollout is a collaborative partnership. We work closely with your engineers, and the overall lead time relies heavily on timely feedback and prompt sample validation from your team.
| Shell Material | |||
|---|---|---|---|
| Number of Positions | |||
| Shell Material | Number of Positions |
| Contact Material | Brass |
|---|---|
| Contact Material | Brass |
| Plating | Gold Plating |
||
|---|---|---|---|
| Mating Cycle | 1000 |
||
| Plating | Gold Plating |
Mating Cycle | 1000 |
| Rated Current | |||
|---|---|---|---|
| Rated Voltage | 500V DC |
||
| Contact Resistance | ≤1.5mΩ |
||
| Insulation Resistance | |||
| Rated Current | Rated Voltage | 500V DC |
|
| Contact Resistance | ≤1.5mΩ |
Insulation Resistance |
| Operating Temperature | -20~120℃ |
||
|---|---|---|---|
| Salt Spray Resistance | 24H |
||
| Ingress Protection | IP40 |
||
| Flammability | UL94 V-0 |
||
| Operating Temperature | -20~120℃ |
Salt Spray Resistance | 24H |
| Ingress Protection | IP40 |
Flammability | UL94 V-0 |
| Shell Material | |
|---|---|
| Number of Positions | |
| Contact Material | Brass |
| Plating | Gold Plating |
| Rated Current | |
| Rated Voltage | 500V DC |
| Contact Resistance | ≤1.5mΩ |
| Insulation Resistance | |
| Operating Temperature | -20~120℃ |
| Salt Spray Resistance | 24H |
| Mating Cycle | 1000 |
| Ingress Protection | IP40 |
| Flammability | UL94 V-0 |
We are a B2B wholesaler dedicated to serving our corporate clients. If you are a business looking for a bulk order, please fill out the form below.
